| HL Mast | STD | - |
|---|---|---|
| HL | 30 m | |
| SHL | 30 m | |
| Additional Weight | STD | - |
| HL | - | |
| SHL | ~ 250 t |
| Max. Lifting Capacity | STD | 450 t 6.7m |
|---|---|---|
| HL | 370 t 8.3m |
|
| SHL | 550 t 8.3m |
|
| Length | STD | 24 ~ 84 m |
| HL | 36 ~ 84 m | |
| SHL | 36 ~ 84 m |
| Max. Lifting Capacity | STD | 300 t 10 m |
|---|---|---|
| HL | 300 t 9.3 m |
|
| SHL | 300 t 20.0 m |
|
| Length | STD | 30 ~ 84 m |
| HL | 36 ~ 84 m | |
| SHL | 36 ~ 84 m |
| Max. Lifting Capacity | STD | 98 t 18.0 m |
|---|---|---|
| HL | 98 t 20.0 m |
|
| SHL | 98 t 30.0 m |
|
| Length | STD | 90 ~ 108 m |
| HL | 90 ~ 108 m | |
| SHL | 90 ~ 126 m |
| Type | STD | A |
|---|---|---|
| HL | B | |
| SHL | B2 | |
| C | ||
| Max. Lifting Capacity | STD | 105 t |
| HL | 120 t | |
| SHL | 120 t | |
| 105 t | ||
| Max. Combination(Boom) | STD | 78 m |
| HL | 78 m | |
| SHL | 78 m | |
| 102 m | ||
| Max. Combination(Jib) | STD | 18 m |
| HL | 18 m | |
| SHL | 18 m | |
| 18 m |
| Max. Lifting Capacity | STD | 195.1 t |
|---|---|---|
| HL | 200 t | |
| SHL | 200 t | |
| Max. Combination(Boom) | STD | 60 m |
| HL | 66 m | |
| SHL | 84 m | |
| Max. Combination(Jib) | STD | 72 m |
| HL | 72 m | |
| SHL | 84 m | |
| Luffing Angle | 66° ~ 86° | |
| Model | HINO E13C-VV |
|---|---|
| Rated Engine Output (Max. Engine Output) |
320 kW / 2,000 min-1{rpm} (330 kW / 1,800 min-1{rpm}) |
| Fuel Tank Capacity | 600 L |
| Max. Line Speed | 110 m/min (1st layer) |
|---|---|
| Rated Line Pull (Single line) | 137 kN {14.0 tf} |
| Wire Rope Diameter | 28 mm |
| Wire Rope Length | 830 m |
| Swing | 0.9 min-1 {rpm} |
|---|---|
| Travel | 1.0 / 0.6 km/h |
| Pumps | 7 variable displacement |
|---|---|
| Max. Pressure | 32 MPa {326 kgf/cm2} |
| Oil Quantity (at the reference level) | 710 L |
| Operating Weight* | Approx. 444 t |
|---|---|
| Ground Pressure* | 142 kPa {1.5 kgf/cm2} |
| Counterweight | 200 t (Upper) |
Units are Sl units. { } indicates conventional units.
* Including base machine, 200.0 t counterweight and 50.0 t carbody weight, 24m STD heavy duty boom and 450t hook block.
