| HL Mast |
STD |
- |
| HL |
30 m |
| SHL |
30 m |
| Additional Weight |
STD |
- |
| HL |
- |
| SHL |
~ 120 t |
| Max. Lifting Capacity |
STD |
300 t × 5.5 m |
| HL |
189.8 t × 8.8 m |
| SHL |
350 t × 8.0 m |
| Length |
STD |
24 ~ 90 m |
| HL |
36 ~ 78 m |
| SHL |
36 ~ 102 m |
| Max. Lifting Capacity |
STD |
26.5 t × 16.1m |
| HL |
- |
| SHL |
- |
| Max. Combination |
STD |
78 m + 30.5 m |
| HL |
- |
| SHL |
- |
| Max. Lifting Capacity |
STD |
40 t × 22m |
| HL |
- |
| SHL |
- |
| Max. Combination |
STD |
72 m + 30m |
| HL |
- |
| SHL |
- |
| Max. Lifting Capacity |
STD |
120 t × 13 m |
| HL |
117.2 t × 13 m |
| SHL |
120 t × 15 m |
| Max. Combination |
STD |
60 m + 66 m |
| HL |
60 m + 90 m |
| SHL |
84 m + 90 m |
| Luffing Angle |
68° ~ 88° |
| Model |
SCANIA DC13 76A |
| Rated Engine Output |
331 kW / 2,100 min-1{rpm} |
| Fuel Tank Capacity |
600 L |
| Line Speed |
115 ~ 3 m/min |
| Rated Line Pull |
147 kN |
| Wire Rope Diameter |
28 mm |
| Wire Rope Length |
600 m (H1)
390 m (H2) |
| Swing Speed (max.) |
1.7 min-1 {rpm} |
| Travel Speed (high/low) |
1.0 / 0.6 km/h |
| Pumps |
8 variable displacement |
| Max. Pressure |
31.9 MPa {326 kgf/cm2} |
| Oil Quantity (at the reference level) |
860 L |
| Operating Weight* |
Approx. 325 t |
| Ground Pressure* |
148 kPa {1.52 kgf/cm2} |
| Counterweight (upper) |
140 t (standard)
160 t (option) |
Units are Sl units. { } indicates conventional units.
* Including base machine, 140 t counterweights and 40 t carbody weights, counterweight self removal device, 24m standard boom and 350t hook block.
Without counterweight self removal device : Working weight 322t, Ground bearing pressure 147kPa.
