| Max. Lifting Capacity |
260 t × 4.6 m |
| Max. Length |
91.4 m |
| Max. Lifting Capacity |
27.0 t × 10.4 m |
| Max. Combination |
76.2 m + 30.5 m |
| Max. Lifting Capacity |
150 t × 7.0 m |
| Max. Combination |
61.0 m |
| Max. Lifting Capacity |
47.1 t × 12.8 m |
| Max. Combination |
91.4 m |
| Max. Lifting Capacity |
80 t × 9.8 m |
| Max. Combination |
61.0 m + 61.0 m |
| Max. Line Speed |
100 m/min (1st layer) |
| Rated Line Pull (Single Line) |
132 kN {13.5 tf} |
| Wire Rope Diameter |
25.4 mm |
| Wire Rope Length |
480 m (Main), 390 m (Aux.) |
| Brake Type |
Spring-set hydraulically releasad(Negative) |
| Swing Speed |
2.0 min-1 {rpm} |
| Travel Speed |
1.1 / 0.7 km/h |
| Model |
HINO P11C-UN |
| Engine Output |
247 kW / 2,000 min-1 {rpm} |
| Fuel Tank Capacity |
370 liters |
| Main Pumps |
4 variable displacement |
| Max. Pressure |
31.9 MPa {325 kgf/cm2} |
| Hydraulic Tank Capacity |
600 liters |
| Standard counterweight removal |
| Operating Weight* |
Approx. 214 t |
| Ground Pressure |
109 kPa {1.11 kgf/cm2} |
| Counterweight |
90.0t (Upper)+24.0t (Lower) |
| Transport Weight** |
Approx. 46.0 t |
Units are SI units. { } indicates conventional units.
Working speeds in table are for light load. Working speed baries with load.
* Including upper and lower machine, counterweight, carbody weight, 12.2m boom, 100 t hook block, and other accessories.
** Base machine with gantry, boom base, crawlers, wire ropes for main and aux. winches, lower spreader and upper spreader.
