| Max. Lifting Capacity |
150 t × 4.4 m*** |
| Max. Length |
76.2 m |
| Max. Lifting Capacity |
26.8 t × 16.0 m |
| Max. Combination |
61.0 m + 30.5 m |
| Max. Lifting Capacity |
80 t × 8.0 m |
| Max. Combination |
47.9 m |
| Max. Lifting Capacity |
44.3 t × 10.6 m |
| Max. Combination |
82.3 m |
| Max. Lifting Capacity |
36 t × 12.0 m |
| Max. Combination |
44.8 m + 53.3 m,
47.9 m + 32.0 m |
| Max. Line Speed |
120 m/min (1st layer) |
| Rated Line Pull (Single Line) |
132 kN {13.5 tf} |
| Wire Rope Diameter |
26 mm |
| Wire Rope Length |
275 m (Main), 255 m (Aux.) |
| Brake Type |
Spring-set hydraulically releasad(Negative) |
| Swing Speed |
2.1 min-1 {rpm} |
| Travel Speed |
1.3 / 0.9 km/h |
| Model |
HINO P11C-UN |
| Engine Output |
247 kW / 2,000 min-1 {rpm} |
| Fuel Tank Capacity |
370 liters |
| Main Pumps |
4 variable displacement |
| Max. Pressure |
31.9 MPa {325 kgf/cm2} |
| Hydraulic Tank Capacity |
535 liters |
| Standard counterweight removal |
| Operating Weight* |
Approx. 136 t |
| Ground Pressure |
106 kPa {1.08 kgf/cm2} |
| Counterweight |
53.0t (Upper)+10.0t (Lower) |
| Transport Weight** |
Approx. 39.7 t |
Units are SI units. { } indicates conventional units.
Working speeds in table are for light load. Working speed baries with load.
* Including upper and lower machine, counterweight, carbody weight, 12.2m boom, 100 t hook block, and other accessories.
** Base machine with gantry, boom base, crawlers, wire ropes for main and aux. winches, lower spreader and upper spreader.
*** Auxiliary sheave is necessary.
