| Max. Lifting Capacity |
100 t ★x 3.3 m |
| Max. Length |
61.0 m |
| Max. Lifting Capacity |
10.9 t × 18.0 m |
| Max. Combination |
51.8 m + 18.3 m |
Max. Line Speed
(1st layer) |
120 m/min |
Rated Line Pull
(Single Line) |
112 kN {11.4 tf} |
| Wire Rope Diameter |
26 mm |
| Wire Rope Length |
240 m (Main), 165 m (Aux) |
Brake Type
(free fall) |
Wet-type multiple disc brake (Optional) |
| Swing Speed |
4.0 min-1 {rpm} |
| Travel Speed |
1.7 / 1.1 km/h |
| Model |
HINO J08E-VM |
| Engine Output |
213 kW / 2,100 min-1 |
| Fuel Tank Capacity |
400 L |
| Main Pumps |
3 variable displacement |
| Max. Pressure |
31.9 MPa {325 kgf/cm2} |
| Oil Quantity (at the reference level) |
380 L |
| Counterweight/self-removal device (Option) |
| Operating Weight |
89.9 t *1 |
| Ground Pressure |
101.3 kPa {1.03 kgf/cm 2} |
| Counterweight |
31,100 kg |
| Transport Weight** |
40,415 kg *2 |
Units are SI units. { } indicates conventional units.
Line speeds in table are for light loads. Line speed varies with load.
*1 Including upper and lower machine, 31.1 ton counterweight, 15.0 ton carbody weight, basic boom, hook, and other accessories.
*2 Base machine with boom base, gantry, crawlers, and wire ropes (front/boom hoist)
★ The value are theoretical result.
